Explosion Proof Portable Led Lighting 10W 15W

Brand Name : KHJ

Model Number : Ex-KFF10,Ex-KFF15

Certification : ATEX,IECEx,CE,RoHS

Place of Origin : Guangdong, China

MOQ : 1pcs

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 400pcs per day

Delivery Time : 3-8 work days

Packaging Details : 275*275*230mm

Product Name : Forestfrog series

Working Voltage : 100-277 VAC,141-392 VDC

Rated Power : 10W 15W

Luminaire Efficacy : 136.5lm/W

Area Classification : Group II Zone 1 & 21 and 2 & 22

Enclosure Material : Die-casting aluminium alloy

Enclosure Colour : Orange,RAL2011

Coating : Epoxy powder coating

Contact Now

LED Explosion Proof Work Light, Forestfrog series,10 hours battery backup for oil tank cleaning

LED Explosion Proof Work Light, Forestfrog series,10 hours battery backup for oil tank cleaning

Highlight:Explosion Proof LED Portable light,Zone 1&2, 10 hours battery back up

Features And Benefits:

1. Copper free aluminum alloy enclosure, high impact resistance tempered glass lens.

2. Vibration and shock resistant.

3. 6 to 10 hours battery back up.

4. With magnetic bracket .

5. Low maintenance and long life span.

Product Differentiation:

Type Of Protection	Ex db, Ex tb
Protection Standards	(IEC)EN 60079-0, (IEC)EN 60079-1, (IEC)EN 60079-28, (IEC)EN 60079-31 EN 55015, EN 61547, EN 61000-3-2, EN 61000-3-3, EN 60598-1, EN 60598-2-5, EN 62031, EN 62493, IEC 62321-4, IEC 62321-5, IEC 62321-6, IEC 62321-7-1, IEC 62321-7-2, IEC 62321-8
Area Classfiction	Zone 1 and Zone 2 Areas to (IEC)EN 60079-10-1,Zone 21 and Zone 22 Areas to (IEC)EN 60079-10-2
Installation	(IEC)EN 60079-14
Certificate	EPT 18 ATEx 2977 X, IECEx CQM 15.0039X
Equipment Coding	Ex db op is IIC T* Gb,Ex tb op is IIIC T* Db
Temperature Class	Rated power (W)	-20℃ ≤ Ta ≤ +55℃
		Gas	Dust
	10W	T6	T80℃
	15W	T6	T80℃
ATEx Coding	II 2 G / II 2 D
Battery Capacity	4.4 Ah
Battery Type	Lithium battery
Battery Lifespan	500 cycles
Light Duration	＞10h(10W)
	＞6h(15W)
Charging Time: (after full discharge)	3h
Ingress Protection	IP66 (IEC)EN 60529
Cable entry	Not applicable
CE Mark	The CE marking of this product applies to EU directives 2014/35/EU, 2014/30/EU, 2012/19/EU , 2011/65/EU and 2014/34/EU respectively. The Equipment is declared to meet the provisions of the ATEX directive(2014/34/EU)by reason of the EC Type Examination and compliance with the Essential Health and Safety Requirements

Applications:
Can be widely used for Zones 1 and 2 (Gas) and 21 and 22 (Dust) hazardous areas where potentially explosive gases, vapours, mists and dusts may be present in a confined space.
1. Oil tank
2. Vessels
3 Routine inspection work.
5. Other oil and gas, aircraft, petrochemical and utility applications
Explosion Proof Portable Led Lighting 10W 15W

Ordering information:

P/N	Operating Voltage(V)	Luminous Flux(lm)	Power(W)	CRI	Color Temp.	CCT(K)	Temp. Classification
P/N	Operating Voltage(V)	Luminous Flux(lm)	Power(W)	CRI	Color Temp.	CCT(K)	-20℃~+55℃
Ex-KFF10H6V6WM-B-E	100~277 AC (141~392 DC)	1260	10	80	Warm white	3000±300	T6
Ex-KFF10H6V6NH-B-E		1365	10	70	Natural white	4000±300
Ex-KFF10H6V6NH-B-E		1365	10	70	Natural white	5000±300
Ex-KFF10H6V6CH-B-E		1365	10	70	Cool white	5700±300
Ex-KFF15H6V6WM-B-E		1890	15	80	Warm white	3000±300
Ex-KFF15H6V6NH-B-E		2047	15	70	Natural white	4000±300
Ex-KFF15H6V6NH-B-E		2047	15	70	Natural white	5000±300
Ex-KFF15H6V6CH-B-E		2047	15	70	Cool white	5700±300

Product Tags:

Explosion Proof Portable Led Lighting 10W

Explosion Proof Portable Led Lighting 15W

Explosion Proof Portable Led Lighting 10W 15W Images
